K1 TLEB101 TLEB102 Non-touch Exit Button Touchless Exit Switch

Description

Original Brand New TLEB101 K1-1 Nontouch Exit Button for Access Control System

Features:

• Door release buttons

• No touch / Touch free Exit Sensor (Diffused Detection)

• Optical / Infrared Technology

• IP-55 Ingress Protection / SUS 304 Stainless steel Plate

• User friendly (Healthy protection)

• Free from contagious diseases spread

• Detection range: 0.1 ~ 10 cm

• Application: Gate/Door/Exit/Automation control

• High capacity of relay dry contact (3A/AC120V,DC30V)

• Normally open/Normally close/Common relay output

• Twin led indicators for sensor standby or approached

• Sensor Standby: BLUE LED ON

• Visitors whom approached to the sensor in 10 cm : RED LED ON

Specifications:

Dimensions	Length 115* width 70* height 38mm (TLEB102) Length 86* width 86* height 38mm (TLEB101)
Switching voltage	DC 9 ~ 16V
Rated Current	2A
Output Contact	NO/NC/COM
Mechanical Life	100,000 tests in 3 months
Operating temp	-20℃～+50℃
Suitable Humidity	10%-95%
Detection range	2-10 cm
LED Indicator	Blue LED: Standby / Red LED: Open
Weight	0.153Kgs
Construction	SUS304 Stainless Steel
Packing List	Machine*1+White rubber plug*2+KA3.5/30 screw*2

TLEB102 ZKTeco nontouch exit switch US Size

TLEB101 ZKTeco nontouch exit switch EU Size

ID 125khz Cards-MF 13.56mhz Cards

Wholesaler/Dealer  inquiry on other Access Control Related Products, please contact us.
